Infrared tunnel sterilizing oven

Yield capability: comply with the whole line

Powder supply: 380V   50HZ, 3 phase, 4 wire

Conveyor speed: 0~180mm/min

Valid width of the mesh: 600mm[depend on the yield capacity and bottle size]

Motor Power used for conveyor: 1.1kw

Max. heating power: 60kw

Temperature regulation range: 0--350℃

Temperature in the area of bottle inlet：    0~150℃

Temperature of High temperature area：    250~350℃

Valid sterilizing time: more than 5min in heating

Temperature in cooling: about 40 ℃

Cooling way: 100c vertical laminar

Air exhaust:  8000~10000m³/h

Wind pressure:  400~500Pa[the air exhausting blower prepared by user]

Outside dimension: 5000×1400×1900

Main component:

The surrounding plate and the parts contacted with bottle is imported good quality SUS 304/2B

Heater: gild quartz heater

Conveyor: SS

Main motor: JIACHENG, shanghai

Blower: Chenguang,Nanjing

Heated resistant HEPA: yiling, shanghai

Thermal couple: Shangyi

Temperature controller:Shangyi
