XS-QX Fully automatic air washing bottle machine:

(Picture is for reference only)

Summary：

This machine use clean compressed air for cleaning  the inter of plastic bottle and glass bottles, sucked another air intakes finished cleaning the air, full sealing device, effective sucked in the bottle and the bottle wall foam powder, dust, water drops and other debris, to achieve the purpose of plastic bottle/glass bottles cleaning. The delivery of the equipment, to fill the gaps in the domestic market, after years of continuous improvement, the models have mature and stable.

Main technical parameters：

l Applicable specifications：50～100mL

l Capacity：12heads (5000- 9000)bottles/hour

l Compressed air pressure：6～8kg/cm2

l Gas consumption：25m3/h

l Power Supply：38 0V 50/60Hz

l Power：1.75Kw

l Single machine noise：≤70dB

l Purifying air：0.2micron

l Cleaning time：3～5second

l Weight：About 500kg

l Machine size：2400×800×1600

Characteristic：

l Simple structure, stable performance, easy operation and low maintenance cost.

l Easy replacement, just adjust the height of the needle and the distance of the cylinder baffle.

l Automatic counting, no bottle no action.

l The device can clear all micro particles in the bottle..

l Clear particles are discharged from the vacuum, do not circulate, pollute the environment.

l The body and parts made of stainless steel 304, polished surface, easy to wash.

l The external of the machine with organic glass cover and door.

l Cleaning quality is in line with the requirements of GMP specification.

Note: because the company's products are constantly updated, if there is any change, without further notice, please kindly understand!
