XS-6G Fully-automatic liquid filling machine

Capability and Characteristic：

This machine is a kind of microcomputer (PLC) programmable control, photoelectric sensor, pneumatic operation in the integration of high-tech filling equipment. Widely used in pesticide, chemical, reagents, detergent, disinfectant liquid filling, lubricating oil and cosmetic, etc. Filling measurement precision, no bubble, no drop leak. Can be used in the 1 ~ 20L bottle shape (including special-shaped bottle) filling.

First.Advanced design:

This machine is suitable for different specifications of the container filling, switch in a few minutes filling specifications.

1.Filling cycle is short, high production capacity.

2.Don't need to add the spare parts, replacement, filling specifications, only need to make an adjustment that is complete.

3.The user can choose according their own production capacity filling quantity to determine filling quotas.

4.Touch operation, can according to production condition, operation procedure and the way of filling. Picture intuitive, simple operation, convenient maintenance.

5.Each filling head a card bottle device, ensure accurate injection material para.

6.Each filling head is equipped with a clamping device to ensure the accuracy of the injection alignment.

Second, the unique way of filling:

1.The design of linear group into the bottle, This way make filling function extension, various shapes of filling containers, can effectively in this equipment.

2.With international advanced pneumatic filling valve, ensure no drip filling process.

3.Powerful PLC software support, which can realize the ideal filling operations.

4.Friendly man-machine interface, all operations are completed on a touch screen.

Third, precise metering control:

1.Filling with fixed port parameters, and time to implement different measurement control filling.

2.Pneumatic valve, filling the precise time can be set to 0.01 seconds, can make the measurement precision is controlled in the range of error of plus or minus 1%, reduce unnecessary material loss, improve the economic benefits of the user.

3.Each measurement of the filling head can be adjusted separately, in order to realize filling the same measurement.

4.The machine set into the counting procedures, no bottle, bottle does not reach the designated position is not filling, only when the counter records to the bottle and set the number of filling bottles is consistent to the filling.

5.Filling quantity, can be adjusted to the required at the beginning of filling amount, fine-tuning again, can get ideal filling measuring accuracy.

Four,Technical parameter:
1 、Model： XS-6G
2 、Filling range： 1L ～ 12L
3 、Filling speed：<1000 Bottles / hour

4 、The calculation precision：± 1%
5 、Rated power： 0.8 Kw
6 、Voltage： 380 V
7 、Working pressure： 6 ～ 7 Kg/cm²
8 、Air consumption： 0.5 cm³/min
9 、Machine weight： 500 Kg

10、Machine size：6000 × 900 × 1900mm
